EDUCATION

Delft University of Technology (TUD)
Master of Science in Electrical Engineering, Microelectronics track
Sept. 2019 – Nov 2021
GPA: 7.86/10

Shanghai Jiao Tong University (SJTU)
Bachelor of Science in Electronic Science and Technology
Sept. 2015 - Jun. 2019
GPA: 84.6/100


THESIS PROJECTS

RoCE based 100Gbps RDMA network stack on FPGA hardware
Master thesis Advisor: Dr. Zaid Al-Ars
Nov. 2020 - Nov. 2021

  • Investigated the alternative solutions in terms of transport layer models and architectures for RDMA network stack for FPGA implementation
  • Studied and contributed to an open source 100 Gbps FPGA network stack IP in High Level Synthesis with C++
  • Developed an open source 100 Gbps RoCE v2 stack for Alveo FPGA platforms which supports direct memory access to both on-board high bandwidth memory (HBM) and host memory
  • Made measurements of throughput and latency for the designed RDMA stack on Xilinx Adaptive Compute Cluster FPGAs at ETH Zurich, which achieves a goodput around 90-95 Gbps and a round trip latency under 4.5 ms for both RDMA READ and WRITE operations

The project is publically available on the Github repositiry.


Simulation and Design of Micro-Ring Optical Filters
Bachelor thesis Advisor: Dr. Xuhan Guo
Apr. 2018 - Sept. 2018

  • Simulated a bandpass optical filter based on micro-ring resonator structure in Lumerical FDTD Solutions, achieving a narrow passband of 0.8nm and a relatively large roll-off in the 1550 nm communication band (C-band)
  • Deduced and modeled the coupling relationship based on transfer matrix method in MATLAB, and simulated Vernier micro-ring structure as well as Coupled-Ring Optical Waveguide (CROW) structure
  • Designed a Vernier micro-ring resonator filter in Lumerical MODE Solutions, achieving a free spectral range larger than 45nm with an extinction ratio greater than 30dB, and an insertion loss below 3dB in the C-band
  • Designed a cascaded micro-ring-based reconfigurable filter consists of eight micro-rings, achieving an FSR of 45 nm, bandwidth adjustment range from 0.43 to 1.25 nm, and central wavelength adjustment range covering the entire FSR
  • Optimized this reconfigurable photonic filter in MODE Solutions simulator, and achieved an insertion loss less than 1dB, an extinction ratio larger than 25dB and passband flatness smaller than 0.5dB over all configurations


SELECTED RESEARCHES & COURSE PROJECTS

Big Data Processing using Spark and Kafka
Advisor: Dr. Zaid Al-Ars
Sept. 2020 - Nov. 2020

  • Developed an application to process OpenStreetMap (OSM) data using Spark in Scala and improved its scalability
  • Packaged the application and deployed it on Amazon EMR clusters to process the entire OSM data set (76 GB)
  • Implemented a streaming application to filter and count records using Kafka Streams DSL and Processor API


SystemC Neural Network
Advisor: Dr. Ir. Rene van Leuken
May. 2020 - Jul. 2020

  • Implemented a one-layer artificial neural network (ANN) on SystemC Virtual Platform (SCVP) in SystemC and C++
  • Optimized hardware resource usage of this design by replacing fix point numbers with integers
  • Optimized the weight update algorithms by implementing backpropagation, which achieved an accuracy of 81% identifying the MNIST digits on the single layer structure with limited training set (64 images)


Design of Time-to-Digital Convertor (TDC)
Advisor: Dr. Morteza Alavi
Feb. 2020 - Apr. 2020

  • Designed the structure of a 5-bit high resolution time-to-digital convertor with 2-D Vernier structure
  • Developed the schematic design of the 2-D Vernier TDC from transistor level in Cadence Spectre
  • Optimized the TDC with buffers and redundant blocks, achieved a time resolution of 6.07ps and good linearity with both integral and differential non linearity below 0.3 in 90nm CMOS technology


SoC Design Based on rVEX Reconfigurable Architecture
Advisor: Dr. Sorin Cotofana
Nov. 2019 - Feb. 2020

  • Performed Design Space Exploration (DSE) simulations via VEX toolchain, optimized the area and performance of the rVEX processor considering computational resources and memory configurations for different applications
  • Designed a SoC based on rVEX architecture to implement target operations, and performed DSE of it on FPGA
  • Designed a dual-core VEX processor to efficiently run the target benchmarks in parallel with minimum idle resources, and optimized the design to be well-balanced among occupied area, execution cycle and power consumption


Design of Discrete-Time Fully Differential Amplifier
Advisor: Dr. Klaas Bult
Nov. 2019 - Jan. 2020

  • Designed a discrete-time fully differential amplifier of a given gain-boosting architecture in 0.18um CMOS in LTSpice
  • Performed AC simulation, transient simulation and noise simulation for this differential amplifier
  • Sized the transistors in the amplifier and achieved 60dB accuracy in 9.78ns with power dissipation of 0.79mW


Optimization of Advanced Computing Systems
Advisor: Dr. Zaid Al-Ars
Sept. 2019 - Nov. 2019

  • Implemented simple SIMD extension (AVX), OpenMP and OpenCL to accelerate benchmarks
  • Applied CUDA for to accelerate an imaging processing pipeline (including ripple effect and Gaussian blur) in C++
  • Implemented CUDA to improve the performance of a k-means clustering algorithm, and achieved a speedup of 90X


Design of Stabilized DC Power Supply
Advisor: Dr. Yan Yuan
Sept. 2017 - Jan. 2018

  • Built a closed-loop stabilized DC power supply using nonsynchronous voltage-mode controller chips, which had a characteristic of a wide input range, an output voltage swing less than 0.8% and an efficiency of 94% at 2A output
  • Developed a human-machine interface for the power supply on the Texas Instruments MSP430 Launchpad, with switch debouncing, manual voltage setting, precise output current monitoring, and power distribution balancing functions


Medical Image Segmentation Based on Machine Learning
Advisor: Dr. Yu Qiao
Oct. 2016 - Oct. 2017

  • Programmed gray scale gradient boundary extraction and distortion correction algorithms by MATLAB
  • Implemented reinforcement learning and traditional active-shape-model algorithm to build an interactive medical image segmentation platform, which enabled doctors to optimize segment results with their experience


Wireless Remote-Control System Based on Microcontroller
Advisor: Dr. Xiaodong Wu
Mar. 2016 - Jun. 2016

  • Established wireless TCP communication between mobile phone App and ESP8266 chip over Wi-Fi connection
  • Designed a voice interactive system using an Arduino Mini board and an MP3 decoding board
  • Built a remote-control system with these two parts, and realized stable connection in 40 meters


INTERNSHIP

FPGA Design Intern at Shanghai Qian Ting Network Technology Co., Ltd.
Research and Development Department
Sept. 2018 - Feb. 2019

  • Developed a format conversion module on Xilinx Spartan-3 FPGA board in Verilog with clock domain crossing method
  • Built a two-way Ethernet communication module by Modelsim and Xilinx ISE, connecting the PHY chip and FPGA through Gigabit Media-Independent Interface (GMII), with CRC-32 redundancy check and packet capture abilities
  • Designed an asynchronous DSP interface on Spartan-3 FPGA board, and realized read/write operations with the DSP
  • Integrated the Ethernet and DSP modules into a whole, realizing network routing and packet filtering functions
  • Designed an synchronous CPU interface on Gaowin FPGA board, and realized communication with an ARM chip


MISCELLANEOUS

Software MATLAB, Vivado/Vitis, Modelsim, Cadence Spectre, LTspice

Programming
Verilog, System Verilog, VHDL, Python, C/C++, bash, Git, MakeFile, LaTeX, TCL scripts, CUDA, Spark

Scholarship KTH scholarship 2019 (30 out of 2000, didn’t accept)

Award The 3rd Prize of SJTU Texas Instruments Cup Electronic Design Competition in 2017

Volunteer Constructed the facilities of a farm in Australia Trentham for a month in 2017

Coursera Java for Android, Machine Learning, HTML CSS and JavaScript

Hobbies Skateboarding (President of SJTU Sk8 Club), Rubik’s Cube (3*3 in 15 seconds), Photography


Updated on 14/12/2021
